YRT580

RDK-High precision bearing with combined load d 325-1030 mm

I want to buy Contact support

Parameter configuration
Property name	Property value
Designation	YRT580
m ≈kg	89
d	580
D	750
h	90
H₁	60
H₂	30
C	30
D₁ max	700
J	610
J₁	720
Inner ring d₁	11.4
Inner ring d₂	18
Inner ring a	11
Quantity	46
Outer ring d_s	11.4
Outer ring Quantity	42
Quantity×t	48×7.5°
G	M12
Quantity	6
M_ANm	68
Axial Dyc C_a N	390000
Axial Stc C_oa N	3600000
Radial Dyc C_r N	211000
Radial Stc C_or N	820000
n_G min^-1	60
M_RL Nm	140
Load center Axial c_rL kN/μm	6.9
Load center Radial c_rL kN/μm	9
Load center capsizing stiffness c_kL kN?m/mrad	380
Rolling units pcs Axial c_rL kN/μm	42.1
Rolling units pcs Radial c_rL kN/μm	17.400
Rolling units pcs capsizing stiffnessc_kL kNm/mrad	2062

Dimensional drawing

Describe

Germany Deke Industrial (Hong Kong) Limited specializes in the sales of RDK-High precision bearing with combined load d 325-1030 mm YRT580, YRT580. The relevant information includes: model YRT580, inner diameter: 580, outer diameter: 750, thickness: . For more information about YRT580, you can consult online or call the hotline: 4006086686. We will serve you in detail.

YRT580 is widely used. YRT580 is mainly used in construction machinery, machine tools, automobile, metallurgy, mining, petroleum, machinery, electric power, railway and other industries. The price of YRT580 sold by our company is reasonable, quality is guaranteed, and all aspects of service are provided to meet the needs of customers.
