| Parameter configuration | |
| Property name | Property value |
|---|---|
| Bearing | 23030-E1A-K-M |
| X-life | XL |
| Withdrawal sleeves | AHX3030 |
| Bearing ≈kg |
7.33 |
| Withdrawal sleeves ≈kg |
1.15 |
| d1H | 145 |
| d | 150 |
| D | 225 |
| B | 56 |
| r min |
2.1 |
| D1 ≈ |
206.3 |
| d2 ≈ |
- |
| ds | 4.8 |
| ns | 9.5 |
| a ≈ |
5 |
| b | 15 |
| Screw thread d2G |
M160×3 |
| I | 72 |
| da min |
160.2 |
| Da max |
|
| ra max |
|
| Dyc Cr |
|
| Stc Cr |
|
| e | |
| Y1 | |
| Y2 | |
| Y0 | |
| Fatigue limit load Cur/ N |
|
| Limiting Speed nG /min–1 |
|
| Reference Speed nB/min–1 |
|
Germany Deke Industrial (Hong Kong) Limited specializes in the sales of RDK-Spherical Roller Bearings d 150-170mm 23030-E1A-K-M, 23030-E1A-K-M. The relevant information includes: model 23030-E1A-K-M, inner diameter: 150, outer diameter: 225, thickness: 56. For more information about 23030-E1A-K-M, you can consult online or call the hotline: 4006086686. We will serve you in detail.
23030-E1A-K-M is widely used. 23030-E1A-K-M is mainly used in construction machinery, machine tools, automobile, metallurgy, mining, petroleum, machinery, electric power, railway and other industries. The price of 23030-E1A-K-M sold by our company is reasonable, quality is guaranteed, and all aspects of service are provided to meet the needs of customers.
