Parameter configuration | |
Property name | Property value |
---|---|
Designation | 3217 |
Mass m ≈kg |
3.44 |
d | 85 |
D | 150 |
B | 49.2 |
r min |
2 |
D1 ≈ | 135.1 |
D2 ≈ | - |
d1≈ | 108.5 |
a ≈ |
106 |
da min |
96 |
Da max |
139 |
ra max |
2 |
Dyc Cr |
112000 |
Stc Cr |
150000 |
Fatigue limit load Cur/ N |
7200 |
Limiting Speed nG /min–1 |
3800 |
Reference Speed nB/min–1 |
4750 |
Germany Deke Industrial (Hong Kong) Limited specializes in the sales of RDK-Angular contact ball bearing d 80-110mm 3217, 3217. The relevant information includes: model 3217, inner diameter: 85, outer diameter: 150, thickness: 49.2. For more information about 3217, you can consult online or call the hotline: 4006086686. We will serve you in detail.
3217 is widely used. 3217 is mainly used in construction machinery, machine tools, automobile, metallurgy, mining, petroleum, machinery, electric power, railway and other industries. The price of 3217 sold by our company is reasonable, quality is guaranteed, and all aspects of service are provided to meet the needs of customers.
